5G MIFI with Qualcomm SDX62 MF100
- 5G NR NSA/SA Support
- High-speed Data Throughput4
- Dual-band Wi-Fi 6 (802.11ax)
- 10,000mAh Battery
- Global Frequency Bands
Global Network Coverage
Supports global 5G/LTE bands and NSA/SA modes for seamless, flexible connectivity across carriers.
Wi-Fi 6 Technology for Faster Internet
Supports 2.4/5GHz bands, up to 32 users per band, with adaptive channel selection.
Flexible SIM Options
1 physical SIM slot (4FF, 1.8V/3.0V) + eSIM, enabling flexible network switching.
Fast Charging Support
Supports 18W fast charging via PD3.0/BC1.2, minimizing device downtime.
Long Battery Life
10,000mAh battery supports ≥17h operation and ≥144h standby (network-dependent).
Robust Device Management
Supports TR069 for remote setup, firmware updates, and real-time diagnostics like ping and trace.
Blazing-Fast 5G Connectivity
Powered by Qualcomm SDX62, supports 5G NR NSA/SA, LTE Cat 19, and AX3000 Wi-Fi, enabling 2.4Gbps DL and ultra-fast multi-device wireless connectivity.
Global Network Coverage
Supports global 5G NR/LTE bands and both NSA/SA modes, ensuring seamless connectivity and adaptability across diverse network infrastructures and carriers.
High-Capacity 10,000mAh Battery for Extended Use
Built-in 10,000mAh battery provides up to 17 hours of operation and 144 hours standby, depending on network conditions.
18W Fast Charging with PD3.0/BC1.2 Support
Supports 18W fast charging via PD3.0 and BC1.2 protocols, ensuring quick recharge and minimal downtime.
Compact & Portable Design
Compact 155×78×17mm, 400g MiFi with built-in 4×4 MIMO NR/LTE and 2×2 MIMO Wi-Fi antennas for enhanced signal and coverage.
Dual SIM with eSIM Flexibility
Offers choice of eSIM or physical SIM (4FF) for adaptable and convenient network access.
Dual-Band Wi-Fi 6 for High Capacity
Supports 2.4GHz/5GHz Wi-Fi 6 (AX3000), adaptive channels, and up to 32 users per band for fast, stable connections.
| Product | MF100 |
| Chipset | Qualcomm SDX62 |
| ROM | 8GB |
| FRAM | 8GB |
| Antenna | 4X4 MIMO |
| Interfaces | 1 x TYPE-C |
| WIFI | 2.4GHz, 5GHz |
| SIM Card | 1.SIM(4FF) Support 1.8V& 3.0V 2.ESIM |
| Battery | Rechargeable lithium battery, Capacity: 3.7V/10000mAh |
| Dimension | 155x78x17mm |
| Operating Temperature | 0~+45ºC |
| Operating Humidity | 5% ~ 95% |
| Cellular | |
| Frequency Band |
5G NR :
N1/ 3/ 5/ 7/ 8/ 20/ 28/ 38/ 40/ 41/ 75/ 76/ 77/ 78
LTE-FDD: B1/ 3/ 5/ 7/ 8/ 20/ 28/ 32 LTE-TDD: B38/ 40/ 41/ 42/ 43 WCDMA : B1/ 5/ 8 |
| Platform | Qualcomm SDX62 |
| 3GPP | Release 16 |
| Theoretical Maximum Bandwidth |
NR_SA:
2.4Gbps (DL)/1Gbps (UL)
NR_NSA: 3.4Gbps(DL)/600Mbps(UL) LTE: 1.6Gbps (DL)/200Mbps (UL) UMTS: 42Mbps (DL)/5.76Mbps (UL) |
| Interfaces | |
| TYPE-C | 1 x TYPE-C |
| SIM | 1 x SIM Slot |
| Indicator | 1.Signal strength indicator 2.Wi-Fi 3.Battery level indicator 4.Message |
| Buttons | 1.Power ON/OFF Button 2.Reset Key |
| Hardware | |
| Chipset | Qualcomm SDX62 |
| DDR3 | 8GB |
| Flash | 8GB |
| WIFI | |
| Frequency | 2.4GHz, 5GHz |
| Channel Bandwidth |
2.4G:
20MHz/40MHz
5G: 20MHz/40MHz/80MHz/160MHz 6G: 20MHz/40MHz/80MHz/160MHz |
| WIFI Output Power | 16dbm/2.4G 15dbm/5G 14dbm/6G |
| Theoretical Maximum Bandwidth | AX3000 |
| Power Supply | |
| Protocol | Support PD3.0/BC1.2 charger with fast charging protocol |
| Fast charging power | 18W |
| Consumption | <10W |
| Battery | |
| Type | Rechargeable lithium battery |
| Capacity | 3.7V/10000mAh |
| Maximum Working Hours: | ≥17H,depending on the network |
| Maximum Standby Hours | ≥144H,depending on the network |
| Certification | |
| CE | In Progress |
| UKCA | In Progress |
| FCC | In Progress |
| Physical Properties | |
| Dimensions | 155x78x17mm |
| Weight | 400g |
| Operating Temperature | 0~+45ºC |
| Storage Temperature | -20~+70ºC |
| Humidity | 95% (No-condensing) |
| Software | |
| Https/Http | Both |
| Internet Settings | Network mode setup, Data switch, Roaming setup |
| APN Setup | APN name, Nat Switch on APN bear, PDP (IPV4/IPV6/IPV4V6), MTU size |
| DHCP Setup | Enable/disable DHCP server, Configure DHCP IP Pool, Configure DHCP Lease Time |
| Static Route | Configure static route access |
| DDNS | Support |
| PCI Lock | Support |
| VPN | L2TP, PPTP, GRE, IPSEC |
| TR069 | HTTP/HTTPS, Supports upload/download the ACS specified file, Support configure & queries parameters |
| Work Mode | NAT/ Router mode |
| Software Update | Web GUI update TR069 update |
5G MIFI with Qualcomm SDX62 (MF100) Specification
FFAIoT MF100 User Manual V1.0.0
